Modernizing Payments with PSD2 & PSD3

At their core, PSD2 (Payment Services Directive) and PSD3 redefine how payments work in Europe. They challenge financial institutions, PSPs, and TPPs to think bigger: to create systems that are secure, transparent, and innovative while protecting consumers and enabling competition. Here’s the big picture:

  1. Enhanced Security: Strong Customer Authentication (SCA), fraud detection, and liability shifts put security at the center.
  2. Open Banking: APIs give third-party providers (TPPs) real-time access to customer data. It's about creating a connected ecosystem.
  3. Consumer Transparency: Clear, detailed transaction data, no hidden fees. Simple. Honest.
  4. Operational Excellence: Faster transaction monitoring, scalable data-sharing, and compliance automation.
  5. Market Competition: Level the playing field—access to payment systems for everyone.

Now here’s the question: How do you make it all work?

The answer: CrateDB. A distributed SQL database that scales effortlessly, analyzes data in real time, and handles both structured and semi-structured data like a pro. It’s built to meet the demands of PSD2 and PSD3. Let’s break it down.

1. Strong Customer Authentication (SCA) & Fraud Prevention

The future of payments is secure by design. CrateDB makes it happen with real-time processing and fraud detection.

Example: Storing SCA Events in CrateDB

Every login attempt, device detail, and geolocation needs to be stored securely and queried instantly. With CrateDB:

CREATE TABLE sca_events (
    user_id TEXT,
    login_time TIMESTAMP,
    device_id TEXT,
    ip_address TEXT,
    location GEO_POINT,
    result TEXT INDEX USING FULLTEXT
);

-- Insert data in real time
INSERT INTO sca_events (user_id, login_time, device_id, ip_address, location, result)
VALUES ('user123', '2024-12-29T10:15:00Z', 'device987', '192.168.1.1', [40.7128, -74.0060], 'SUCCESS');


CrateDB can process millions of these events per second, enabling real-time fraud analysis.

Learn More: CrateDB Real-Time Performance

2. Fraud Prevention: IBAN Verification

Matching IBANs with account names is crucial to prevent fraud. CrateDB handles large-scale joins across datasets.

Example:  Large transaction table containing millions of rows and need to join it with an IBAN registry to validate account details while applying filters to extract specific data.

SELECT
    t.transaction_id,
    t.transaction_date,
    t.transaction_amount,
    ir.iban,
    ir.account_name
FROM
    transactions t //millions of rows
INNER JOIN
    iban_registry ir
ON
    t.iban = ir.iban
WHERE
    ir.iban = 'DE89370400440532013000'
    AND ir.account_name = 'John Doe';

This query executes instantly—even on billions of records—thanks to CrateDB’s distributed SQL engine combined with the power of columnar storage and indexes on all columns by default.

Learn More:
CrateDB for Fraud Detection

3. Open Banking and API Access

APIs are the bridge between banks and TPPs. CrateDB ensures secure, fast, and reliable data exchange.

Example: Real-Time Consent Management

CrateDB stores and updates customer consent data in real time, empowering PSPs to provide transparency through a dashboard. Here some key benefits of CrateDB in consent management:

  • Time-Series Optimization: Tracks consent changes efficiently over time.
  • JSON Flexibility: Easily stores and queries dynamic consent data structures.
  • Geospatial Insights: Adds location-based analysis for consent events.
  • High Scalability: Handles millions of records with ease.
  • Retention Policies: Automatically manages storage of expired records.

Below is an example of how consent management implemented using CrateDB.

CREATE TABLE consent_management (
    user_id TEXT NOT NULL,                  -- Unique identifier for the user
    consent_id TEXT PRIMARY KEY,            -- Unique identifier for the consent record
    consent_data OBJECT(DYNAMIC) NOT NULL,  -- JSON object to store consent details
    status TEXT NOT NULL,                   -- Status: granted/revoked/expired
    timestamp TIMESTAMP NOT NULL,           -- Time of consent action
    geo_location GEO_POINT,                 -- Optional: Geo-location of consent action
    metadata OBJECT(DYNAMIC)                -- Optional: Additional metadata
) WITH (
    number_of_replicas = 1,                 -- Adjust based on redundancy needs
    column_policy = 'dynamic'               -- Allows flexible JSON fields
);

-- Below some example records to track consent actions over time
INSERT INTO consent_management (
    user_id, consent_id, consent_data, status, timestamp, geo_location, metadata
)
VALUES
    (
        '12345',
        'consent_001',
        { "consent_type": "email_marketing", "details": "Subscribed to promotional emails" },
        'granted',
        '2025-01-12T14:32:00Z',
        [40.7128, -74.0060],  -- New York City coordinates
        { "device": "mobile", "browser": "Chrome" }
    ),
    (
        '67890',
        'consent_002',
        { "consent_type": "data_sharing", "details": "Consent to share anonymized data" },
        'revoked',
        '2025-01-10T10:20:00Z',
        [51.5074, -0.1278],  -- London coordinates
        { "device": "desktop", "browser": "Firefox" }
    );

 Learn More: CrateDB API Use Cases

4. Data Sharing for Open Banking

CrateDB supports semi-structured JSON, making it perfect for storing and querying TPP-related data. Each payment rail (ACH, card, check, cross-border, etc.,) has its unique data structure. Using JSON in CrateDB allows modeling this diversity while keeping the schema flexible and adaptable to changes.

Example: JSON Data for Open Banking APIs

CrateDB supports semi-structured JSON, making it perfect for storing and querying TPP-related data. Each payment rail (ACH, card, check, cross-border, etc.,) has its unique data structure. Using JSON in CrateDB allows modeling this diversity while keeping the schema flexible and adaptable to changes.

CREATE TABLE payment_rails (
    payment_id TEXT PRIMARY KEY,              -- Unique payment identifier
    user_id TEXT NOT NULL,                    -- Associated user
    payment_type TEXT NOT NULL,               -- Payment rail (ACH, card, check, etc.)
    payment_data OBJECT (DYNAMIC) NOT NULL,   -- JSON data for specific rail details
    tpp_id TEXT,                              -- Third-party provider (TPP) identifier
    timestamp TIMESTAMP NOT NULL              -- Payment initiation timestamp
) WITH (
    number_of_replicas = 1,                   -- Adjust replication for availability
    column_policy = 'dynamic'                 -- Allows adding flexible fields in JSON
);

-- Query a specific TPP request
INSERT INTO payment_rails (
    payment_id, user_id, payment_type, payment_data, tpp_id, timestamp
)
VALUES
    -- ACH Payment
    (
        'payment_001',
        'user123',
        'ACH',
        {
            "account_number": "123456789",
            "routing_number": "987654321",
            "amount": 500.00,
            "currency": "USD",
            "description": "Monthly rent payment"
        },
        'tpp_001',
        '2025-01-12T10:00:00Z'
    ),
    -- Card Payment
    (
        'payment_002',
        'user123',
        'Card',
        {
            "card_number": "**** **** **** 4242",
            "amount": 150.25,
            "currency": "USD",
            "merchant": "Online Store",
            "transaction_id": "txn_12345"
        },
        'tpp_002',
        '2025-01-12T11:00:00Z'
    ),
    -- Cross-Border Payment
    (
        'payment_003',
        'user456',
        'Cross-Border',
        {
            "iban": "DE89370400440532013000",
            "swift_code": "COBADEFFXXX",
            "amount": 1000.00,
            "currency": "EUR",
            "beneficiary_name": "John Doe"
        },
        'tpp_003',
        '2025-01-12T12:00:00Z'
    ),
    -- Check Payment
    (
        'payment_004',
        'user789',
        'Check',
        {
            "check_number": "1001",
            "amount": 250.00,
            "currency": "USD",
            "payee_name": "Electric Utility Co.",
            "issue_date": "2025-01-10"
        },
        NULL, -- No TPP involved
        '2025-01-12T09:00:00Z'
    );

Learn More: CrateDB and JSON

5. Consumer Transparency

Give consumers what they deserve: clear, detailed transaction data. CrateDB enables real-time storage and querying for transparency.

Example: Storing ATM Charges

CREATE TABLE atm_charges (
    transaction_id TEXT,
    user_id TEXT,
    amount DOUBLE,
    fee DOUBLE,
    currency TEXT,
    timestamp TIMESTAMP
);

-- Query fees for a specific user
SELECT transaction_id, fee
FROM atm_charges
WHERE user_id = 'user123';

And with tools like Grafana, CrateDB powers dashboards that display anomalies instantly.

6. Enhanced Transaction Monitoring

Transactions don’t just happen—they tell a story. CrateDB’s time-series capabilities help you analyze every detail.

Example: Monitoring Transactions in Real Time

CREATE TABLE transactions (
    transaction_id TEXT,
    user_id TEXT,
    timestamp TIMESTAMP,
    amount DOUBLE,
    currency TEXT,
    location GEO_POINT
);

-- Query for suspicious transactions (e.g., over €10,000)
SELECT *
FROM transactions
WHERE amount > 10000.00;

And with tools like Grafana, CrateDB powers dashboards that display anomalies instantly.

Learn More: CrateDB Time-Series Analytics

7. Compliance and Audit Trails

Compliance isn’t optional—it’s a necessity. CrateDB logs every action and event for full traceability.

Example: Audit Log

CREATE TABLE audit_log (
    event_id TEXT PRIMARY KEY,
    user_id TEXT,
    action TEXT,
    timestamp TIMESTAMP
);

-- Store an audit event
INSERT INTO audit_log (event_id, user_id, action, timestamp)
VALUES ('evt001', 'user123', 'LOGIN_ATTEMPT', '2024-12-29T10:15:00Z');

CrateDB ensures these logs are immutable, meeting strict compliance requirements.

Learn More: CrateDB and Log Analysis

Why CrateDB Stands Out

  • Real-Time Analytics: Process billions of rows of data instantly.
  • Scalable and Distributed: Built to grow with your business.
  • JSON + SQL: The flexibility of JSON with the power of SQL.
  • Cost-Effective: Designed for massive workloads without massive costs
Let’s Build the Future of Payments.
PSD2 and PSD3 aren’t just regulations—they’re opportunities. With CrateDB, you’re ready to create a secure, transparent, and scalable payment ecosystem. It’s time to innovate.
